ZIPSCAN IS-2210 1D Wired Scanner

Contact for Price

This compact barcode scanner combines high precision with a single laser scan type and a speed of ≥150 scans/s. It supports multiple interfaces including USB-HID, USB-COM, PS2, and RS232. Designed for durability, it withstands drops from 1.5 meters and operates in a broad temperature range. It covers a variety of symbologies and features scan angles of yaw 55°, rotation 30°, and pitch 65°.

SKU: ZIP-IS2210

Compare

Add to wishlist

12 People watching this product now!

Pick up from the Woodmart Store

To pick up today

Free

Courier delivery

Our courier will deliver to the specified address

2-3 Days

Free

DHL Courier delivery

DHL courier will deliver to the specified address

2-3 Days

Free

Warranty 1 year

More details

Free 30-Day returns

More details

Payment Methods:

Device Issue / Installation ? Click here

Description

Physical Parameters Dimensions: 83mm*70mm*172mm Weight: 128.5g Material: ABS+PC Cable Length: 2M

Opera�ng Temperature: -20~ 50 Rela�ve Humidity: 5% ~95% RH(Non-condensing) Shock Resistance: Withstands mul�ple �mes 1.5 meters drops to concrete Storage Temperature: -40 ~70 Environmental Parameters Electronic Parameters Working Voltage: DC5V±1% Opera�ng Current: 85mA.

Performance Parameters

Precision: ≥3mil

Scan Tpye: Single Laser Scan Speed: ≥150 times/s

Light Sources: 650nm laser (Safe visible laser diode)

Depth of scan field: 10-280mm(0.33mm, PCS90%)

Error Rate: 1/5million Interface : USB-HID, USB-COM, PS2, RS232

Supported Symbologies: UPC- A, UPC-E, EAN-13, EAN-8, Codabar, Code 39, Code 39 Full ASCII, China Post, Plessey, MSI, Code 93, Code 128, Industrial 2 of 5, Interleave 2 of 5, Matrix 2 of 5, Code 11, ISBN, ISSN, Code 32(Italian pharm code), Code 39 extended, GS1-128 and ITF-14, SISAS, GS1 Omnidirectional, GS1 Limited, Aviation25, RSS 14.

Scan Angle: Yaw 55°, Rota�on 30°, Pitch 65°

Scan Mode: Manual/Continuous/Automatic Scintillation /Automatic Induction Scanning
