طابعة سطح المكتب Zebra BIXOLON XD5-40T مع USB. USB HOST وSerial وEthernet

Printer Specifications Print Method XD5-40d: Direct Thermal XD5-40t: Thermal Transfer or Direct Thermal Print Speed XD5-40d: Up to 7 ips (178 mm/sec) XD5-43d: Up to 5 ips (127 mm/sec) XD5-40t: Up to 6 ips (152 mm/sec) XD5-43t: Up to 4 ips (102 mm/sec) Print Resolution XD5-40d, 40t: 203 dpi XD5-43d, 43t: 300 dpi Print Width XD5-40t: Up to 108 mm XD5-43t: Up to 105.7 mm Print Length Up to 1,000 mm Sensor Transmissive (Fixed), Reflective (Adjustable), Head Open Media Characteristics Media Type Gap, Black Mark, Notch, Continuous, Fan-Fold Media Width 15 ~ 118 mm Media Roll Diameter Up to 127 mm Media Thickness 0.06 ~ 0.20 mm Supply Method Easy Paper Loading Inner Core 25.4 ~ 38.1mm Ribbon Characteristics Ribbon Type Wax, Wax / Resin, Resin, Outside Ribbon Width 33 ~ 110 mm Ribbon Length Up to 300 m Core Inner Diameter 25.4 mm, 12.7 mm Physical Characteristics Dimensions (WxDxH) XD5-40d: 194 x 248 x 169 mm (7.64 x 9.76 x 6.65 inch) XD5-40t: 2 10 x 284 x 188 mm (8.3 x 11.2 x 7.4 inch) Weight XD5-40d: 1.89kg (4.17 lbs.) XD5-40t: 2.48kg (5.46 lbs.) Electrical EnergyStar Certified, External Power Adaptor 100-240V AC, 50/60Hz Display Standard: None Optional: FSTN LCD (200 x 100 pixels)

Performance Characteristics Memory STD: 64 MB SDRAM, 128 MB Flash Optional: ① 64 MB SDRAM, 128 MB Flash ② 256 MB SDRAM, 256 MB Flash Interface Standard: USB + USB Host Optional: ① USB + USB Host + Serial + Ethernet ② U SB + USB Host + Serial + Ethernet + WLAN ③ U SB + USB Host + Serial + Ethernet + BluetoothXD5-40tR (RFID) Standard: USB + USB Host + Serial + Ethernet Optional: ① USB + USB Host + Serial + Ethernet + WLAN ② U SB + USB Host + Serial + Ethernet + Bluetooth ————————————————————–WLAN: 8 02.11a/b/g/n (Infrastructure, Ad-hoc, Wi-Fi Direct, SoftAP) – WEP40/104, WPA1/2 (PSK, EAP) Bluetooth: V5.0 (MFi certified) Ethernet: 10/100Mbps Real Time Clock Supported (Option) Environment Characteristics Temperature Operating: XD5-40d: 0 ~ 40℃ (32 ~ 104℉) XD5-40t: 5 ~ 40℃ (41 ~ 104℉) Storage: -20 ~ 60℃ (-4 ~ 140℉) Humidity Operating: 10 ~ 80% RH Storage: 10 ~ 90% RH Software Emulation SLCS™, BPL-Z™, BPL-E™, BPL-D™ (Optional) Driver / Utility Windows Driver (Europlus / Seagull) Linux / Mac CUPS Driver Virtual COM USB / Ethernet Driver Utility Program OPOS / JPOS Driver Bartender Ultralite for BIXOLON Label Artist™-II SAP® Device Driver SDK / Plugin Android / iOS / Windows SDK, Linux SDK Chrome SDK, Xamarin SDK, Web Print SDK Application Label Artist™ Mobile (Android, iOS), mPrint App (Android, iOS) MDM (Optional) BIXOLON Profile Manager – XPM™, XCM™ (Windows, Android)

Fonts / Graphics / Symbologies Fonts Bitmap Fonts (10 SLCS™, 16 BPL-Z™, 5 BPL-E™, 9 BPL-D™), Scalable Fonts (1 SLCS™, 1 BPL-Z™, 1 BPL-D™), 23 Code page, Unicode supported (UTF-8, UTF-16LE, UTF-16BE) Graphics Supporting user-defined fonts, graphics, formats and logos Barcode Symbologies 1D: Codabar, Code 11, Code 39, Code 93, Code 128, EAN-13, EAN-8, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, Plessey, Postnet, GS1 DataBar (RSS-14), Standard 2-of-5, UPC/EAN extensions, UPC-A, UPC-E, IMB 2D: Aztec, Codablock, Code 49, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR code, TLC 39 Accessories Standard Cable-USB Optional Peeler, Auto Cutter, External Paper Supply, Serial cable Supplies B-ribbon™, B-band™ RFID Frequency UHF, 865 ~ 868MHz (EU), 902 ~ 928MHz (KR, USA) Transmit Power 1W Modulation ASK Protocol ISO 18000-6C(EPC Class1 Gen2) Auto Cutter Optional Tag Pitch Min 16mm
