طابعة الباركود BIXOLON SRP770

المميزات والمواصفات

Print Characteristics

Print Method: Direct Thermal

Print Speed: Up to 5 ips (127 mm/s)

Print Resolution: 203 dpi

Print Width: Up to 104 mm

Print Length: 6 ~ 304 mm

Printing Length: 6 ~ 1,000mm

Media Sensor: Transmissive, Reflective, Head open

خصائص الوسائط

Media Type: Gap, Black Mark, Notch, Continuous, Fan-Fold

Media Width: 42 ~ 106 mm

Media Roll Diameter: Up to 130 mm

Media Roll Diameter: 0.06 ~ 0.20 mm

Supply Method: Easy Paper Loading

الخصائص الجسدية

Dimensions (W x L x H): 184 x 221 x 171 mm

(7.24 x 8.70 x 6.73 inch)

Weight: 1.65 kg (3.63 lbs.)

Power: External Power Adaptor 100-240V AC, 50/60Hz

Performance Characteristics

Memory: 512KB SDRAM, 2MB FlashROM

Interface: Triple Interface

USB V1.1 FS + Serial + Parallel

Environment Characteristics

Temperature: Operating: 0 ~ 40℃ (32 ~ 104℉)

Storage: -20 ~ 60℃ (-4 ~ 140℉)

Humidity: Operating: 10 ~ 80% RH

Software

Emulation: SLCS, BPL-Z™, BPL-E™

Driver: Windows Driver, Linux CUPS Driver, Mac Driver,

Virtual COM USB Driver, Utility Program, Label Artist™

SDK: Android SDK

Fonts / Graphics / Symbologies

Fonts:

• 10 SLCS Resident Bitmap Fonts
• One SLCS Resident Scalable Font
• 23 Code Page

Graphics: Supporting user-defined fonts, graphics, formats, and logos

Barcode Symbologies: 1D: Coda Bar, Code39, Code93, EAN-8, EAN-13, Interleaved 2-of-5, ITF, UCC/EAN-128, UPC-A, UPC-E

2D: Data Matrix, MaxiCode, PDF417, QR Code
